Fractal Design Terra Graphite SFF PC Case, Mini ITX, Walnut Front, Anodized Aluminium Exterior, 322mm GPU Support, Requires SFX-SFX-L PSU,

Fractal Design Terra Graphite SFF PC Case, Mini ITX, Walnut Front, Anodized Aluminium Exterior, 322mm GPU Support, Requires SFX/SFX-L PSU, USB-C

Name: Fractal Design Terra Graphite SFF PC Case, Mini ITX, Walnut Front, Anodized Aluminium Exterior, 322mm GPU Support, Requires SFX/SFX-L PSU, USB-C
Brand: FRACTAL
SKU: FD-C-TER1N-01
Availability: InStock

£174.10

Description

Specification

Form Factor: Mini ITX
#Hide#Small Form Factor: Yes (SFF)
Power Supply Wattage: No PSU
Motherboard Support: Mini ITX
#Hide#Window(s): No
Connectors / Controls: 1 x USB 3.1 Gen2 Type-C
1 x USB 3.0
Power Button
Drive Bays: 2 x Dedicated 2.5″””” Drive Mounts
Expansion Slots: 3 Expansion Slots
Cooling System: Included
None

Fan Mounts
Bottom: 1 x 120 mm
.:
Radiator Support:
Side: 1 x 120 mm (121mm wide if 200mm GPU and no SSDs)
Colour: Graphite
Material: Anodized aluminium exterior
Front and back: 8mm CNCd anodized aluminium
Front panel: walnut
Compatibility: GPU max length: 322 mm
Configured for Max GPU:
GPU max width 1: 72 mm (GPU height lower than 131mm)
GPU max width 2: 62 mm (GPU height 131-145mm)
GPU max height: 145 mm
CPU cooler max height: 48 mm

Configured for Max CPU-Cooler:
GPU max width 1: 43 mm (GPU height lower than 131mm)
GPU max width 2: 33 mm (GPU height 131-145mm)
GPU max height: 131 mm
CPU cooler max height: 77 mm

PSU:
SFX & SFX-L only
Weight/Dimensions: 3.1 kg
(LxWxH) 343 x 153 x 218 mm
w/o feet/protrusions/screws: 343 x 153 x 198 mm
10.4 litres (non-protruding parts)
Additional Features: See Overview
Click here for Installation Manual
Accessories: Accessory box
Manual
Package Weight: 4.2000 kg
Warranty: 2 Years

Compare

SKU: FD-C-TER1N-01 Category: Cases Tags: 322mm GPU Support, Anodized Aluminium Exterior, Fractal Design Terra Graphite SFF PC Case, Mini ITX, Requires SFX/SFX-L PSU, Walnut Front Brand: FRACTAL

Description

Despite its modest 10.4L, the Terra can easily accommodate a fullsize current GPU and SFX-L PSU thanks to a sliding wall design that adapts to your motherboard and GPU needs

This is a case that fuses Scandinavian design elements and a remarkably flexible interior to form a uniquely versatile SFF case and lend an air of luxury to any build.

Sandwich type SFF-case
Motherboard bracket can be slid sideways to make room where it is needed the most
Anodized aluminum exterior
Front and back panel made by 8 mm CNCd anodized aluminum
Front panel made of walnut
PCIe 4.0 Riser cable included
Removable top panel and removable falcon hinged side panels for easy access
Only 10,4L (non-protruding parts) yet accommodates up to a 322 mm long GPU

Elegantly crafted

Add natural materials to your setup with a front-facing panel cut from FSC-certified solid walnut
Enjoy a sleek anodized aluminum exterior including an 8 mm-thick aluminum front
Make the most of natural airflow through the ventilated top, side and bottom panels

Engineered for SFF gaming

Experience powerful, uncluttered gaming, with the ability to install a GPU up to 322 mm long in a space-saving 10.4 L case
Get a head start on your build with the included PCIe 4.0 riser cable
Store up to two SSDs in the dedicated 2.5” drive mounts

Easily accessible

Slide open the top with an integrated tab and lift open the fully removable side panels for easy access to your components

Adjustable motherboard plate

Find your build’s ideal balance with 30 mm of internal flexibility provided by a stepless, movable central wall

Slide to strike the best ratio for your build, adapting the space for CPU cooling on one side and graphics card width on the other

Front-facing I/O

The solid walnut front panel features an aluminum power button and two USB ports for connecting devices, including one USB Type-C 20Gbps

Natural material

Enjoy a naturally unique finish, with an individual front panel cut from solid walnut.

Highly transportable

Features the ability to lock the top and side panels for safer transportation of your build
